Plastic closure manufacturer in Zibo, China

Zibo Nuofan Packaging Technology Co., Ltd. manufactures plastic caps, carry handles, decorative over-caps and PET preforms in Zibo, Shandong.

We supply water bottlers, beverage producers and packaging distributors with existing models and custom mould development based on bottle drawings or samples.

NUOFAN factory entrance in Zibo, Shandong

Factory & production

Injection moulding, tamper-band processing, printing and packing support our closure production. The process and inspection requirements depend on the selected model.

Rows of injection moulding cells and robotic handling equipment on the factory floor

Injection moulding

Material and processing conditions are selected for each component. Catalogue caps and handles use PP; preforms use PET. Decorative over-cap materials vary by model. Dimensions are reviewed against the approved drawing.

Production specification points
  • Material grade and batch identification
  • First-off dimensions against the approved drawing
  • Component weight and moulding consistency
Operator working at the automated tamper-ring slitting and assembly machine

Tamper-ring slitting

For closures with a slitted tamper-evident band, the cutting process forms connecting bridges. Bridge geometry and band separation are relevant to opening performance and must match the approved closure design.

Production specification points
  • Slitting position and bridge geometry
  • Band separation during sample opening
  • Liner or gasket assembly, where specified
Cap finishing line with automatic output conveyor feeding collection cartons

Printing & finishing

Top printing is prepared from customer artwork. Colour and print position are confirmed against an approved physical sample before production.

Production specification points
  • Print position and approved colour reference
  • Print finish and curing requirements
  • Visual condition: short shots, flash and contamination
Export carton with a sealed polythene liner being filled with red bottle caps

Bagging, cartoning & loading

Caps are packed in lined cartons to protect them during handling and transport. Carton quantity, dimensions, markings and shipping documents are confirmed for the order.

Production specification points
  • Liner and carton closure
  • Agreed quantity per carton
  • Buyer-specified carton markings

Factory visits & shipment coordination

Factory visits, live video tours and buyer-appointed inspections can be discussed with our team. Scope, timing and access are agreed in advance. Goods are prepared for dispatch after packing and order checks; availability and production schedules are confirmed for each order.

Arrange a visit
Finished-goods warehouse
Finished-goods warehouse
Output conveyor to packing
Output conveyor to packing
Loading in the factory yard
Loading in the factory yard
Sales office
Sales office

Quality & documentation

Closure evaluation considers dimensional fit, sealing, opening performance and the intended filling and storage conditions. Requirements and supporting documents are reviewed for each project.

Material specification
Catalogue materials vary by component, including PP caps and handles, PET preforms and PS or PVC decorative over-caps. Resin grade, colourants and intended contact conditions require review for the selected product.
First-off approval
First-off samples are evaluated against the approved drawing and sample. Critical dimensions and tolerances form part of the production specification.
Closure performance requirements
For screw closures, application and removal torque are evaluated with the intended bottle. Sampling frequency and acceptance limits are defined in the inspection plan.
Packing requirements
Packing liners, carton quantities and handling requirements are specified to protect components during storage and transport.
Inspection scope and acceptance criteria

These are requirements for review, not reports of completed tests or certification. Methods, sampling plans and acceptance criteria must be agreed for the selected product.

TestMethodRequirementStatus
Removal torqueAgreed torque measurement procedureWithin the band agreed for your neck and filling lineInspection plan to be agreed
Application torqueAgreed torque measurement procedureSet so the cap seals without cracking the finishInspection plan to be agreed
Tamper band bridge strengthIn-house methodOpening behaviour to the approved band designInspection plan to be agreed
Leakage, invertedIn-house methodLeakage criteria, duration and conditions to be agreedInspection plan to be agreed
Dimensional checkGauge and caliper against the drawingWithin the tolerance on the approved drawingInspection plan to be agreed
Drop test, filled unitAgreed filled-container drop procedureNo leak or fracture after dropTest arrangement to be confirmed
Top loadAgreed container compression procedureNo collapse below the agreed loadTest arrangement to be confirmed
Overall migrationApplicable market method and contact conditionsApplicable overall migration limitNo third-party report currently available
Specific migrationApplicable substance restrictionsWithin the SML for each listed substanceNo third-party report currently available
Heavy metalsApplicable material and market requirementsBelow the declared limitsNo third-party report currently available

Torque requirements apply to the bottle and closure assembly. Neck finish, sealing system, capper settings, filling temperature and storage conditions must be considered before a working range is approved.

Available documentation

Identify the destination market and required documents at the enquiry stage. Additional testing scope, cost and schedule require agreement before order acceptance.

No third-party food-contact report yet

Third-party overall and specific migration reports are not currently available. Testing requirements are reviewed against the material, food type, contact conditions and destination market. Laboratory scope, cost and schedule are subject to agreement.

Food-contact compliance documents

We do not currently provide an EU 10/2011 declaration of compliance or LFGB test report, and do not claim FDA compliance. A material description alone does not establish compliance of the finished article for its intended use.

Quality-system certification

NUOFAN does not currently hold ISO 9001 or BRC certification. Please state any mandatory supplier-certification requirements before proceeding with product qualification.

Patents & industry recognition

The documents and awards displayed below name 淄博银德环保科技有限公司 (Zibo Yinde) as the recorded rights holder or recipient. They are not presented as registrations or awards issued to NUOFAN, or as food-contact certification.

Utility-model patent certificate for the tamper-evident bottle cap
Chinese utility-model patent for the tamper-evident ring structure.
  • ZL 2022 2 3033530.5

    Utility-model patent — tamper-evident bottle cap

    Granted by CNIPA on 28 March 2023, publication CN 218752452 U. Registered scope: a tamper-evident bottle cap.

  • ZL 2022 2 2829413.3

    Utility-model patent — high-precision cap ring-slitting machine

    Granted by CNIPA on 17 February 2023, publication CN 218488588 U. Registered scope: cap ring-slitting equipment.

  • ZL 2022 2 2829412.9

    Utility-model patent — feed assembly for cap moulding machines

    Granted by CNIPA on 28 March 2023, publication CN 218748806 U. Registered scope: a feed assembly for cap moulding equipment.

  • 2024SR1475743

    Software copyright — plastic product design and manufacturing platform

    Registered with the Copyright Protection Centre of China on 9 October 2024, certificate 软著登字第13879616号.

Industry association awards

2025 · Outstanding Exhibitor
Shanshui China · Drinking Water Industry Development Conference, Nanjing
2024 · Industry Contribution Award
China Drinking Water Industry Strategic Summit, Central Forum
2023 · Outstanding Contribution Award
1314 Drinking Water Development Conference

Trade shows & customer meetings

Product samples and closure designs are presented for discussion with bottlers and industry customers.

Drinking-water industry exhibition stand
Drinking-water industry exhibition stand
Reviewing closure samples
Reviewing closure samples
Caps, handles and non-spill closure samples
Caps, handles and non-spill closure samples

Discuss your product or arrange a factory visit

Send a bottle drawing or sample, your quantity and any documentation requirements.
